Ethernet Gigabit PoE Injector 24V 48V 12V

Features Passive POE ( Power Over Ethernet ) adapter, uses unused pairs of 100baseT network cable to transmit power to remote device. Pin out DC jack center positive, It is compatible with equipment supporting the standard PoE pin out ( Pins 4 , 5 Power Pins 7 , 8 Power- ) Specifications 1, Passive DC power Injector / Splitter 2, Ethernet Connection Two 10 / 100BaseT ( RJ-45 ) 3, Power Connection : One male 2.1 mm ( ID ) , 5.5 mm ( OD ) 4, 5V,7.5V,9V,12V,24V,48V are available ! Input/Output Specifications Max DC Input Voltage : 48V Max DC Output Voltage : 48V Max Output Current : 0.4A Over Current Protection : YES General Specifications Operating Temperature: 0°C – 60°C Storage Temperature : -30°C – 70°C Case of material : PVC Ethernet Date Rate : 10 / 100Mbps Ethernet cable : TIA / EIA 568 Cat5 Humidity : Up to 90% Weight : 35g DC Jackets : 2.1 x 5.5 x 12mm Size :71 x 28 x 20mm Single Port black color 1000 Mbps Gigabit POE Cube 24V 48V Ethernet PoE Power Injector   Show More Show Less
