MX1508 Dual H Bridge DC PWM Stepper Motor Driver

MX1508 Dual H Bridge DC PWM Stepper Motor Driver The MX1508 Dual H-Bridge DC Motor Driver is a compact and cost-effective module designed for controlling two DC motors or a single 4-wire, 2-phase stepper motor. It is widely used in applications such as battery-powered smart cars, toy vehicles, and robotics projects. Technical Specifications: Motor Control: Capable of driving two DC motors or one 4-wire, 2-phase stepper motor. Voltage Range: Operates with a supply voltage between 2V and 10V DC. Signal Input Voltage: Accepts control signals ranging from 1.8V to 7V. Current Handling: Continuous operating current: 1.5A per channel. Peak current: Up to 2.5A per channel. Protection Features: Built-in thermal shutdown protection with hysteresis. Integrated flyback diodes to handle reverse EMF voltage spikes. Low standby current consumption (less than 0.1µA). Design: Compact size: Approximately 24.7mm x 21mm x 5mm. Utilizes both P-channel and N-channel MOSFETs in a dual H-bridge configuration. PWM Control: Supports Pulse Width Modulation (PWM) for speed regulation of motors. Additional Features: Built-in common conduction circuit to prevent malfunction when input pins are left floating. Suitable for applications requiring bidirectional motor control. Package Includes: 1 Piece- MX1508 Dual H Bridge DC PWM Stepper Motor Driver
