FOXBORO FBMSVH | FBM Series Vertical Mounting Carrier 10-Slot

Description Product Introduction You’ve got a cabinet full of FBM200 series analog and digital modules. They need a home. The FBMSVH is that home—a 10-slot vertical carrier that holds the modules, provides the backplane communication, and gives you terminals to land field wiring. It’s the backbone of a Foxboro I/O rack. What’s the “VH” stand for? Vertical Horizontal? No—Vertical High-density. Unlike the older FBMSH (horizontal mount), the FBMSVH mounts vertically, which saves panel width. In my experience, this matters when you’re retrofitting older cabinets with limited space. The carrier includes all the termination points for field wiring—you land your signals directly on it, then plug the FBM modules in. No separate termination panels needed. Key Technical Specifications Parameter Value Model FBMSVH Brand Foxboro / Schneider Electric Series FBM 200 / FBM 2000 Series Product Type I/O Carrier / Termination Assembly Number of Slots 10 Mounting Orientation Vertical Module Compatibility All FBM200 and FBM2000 series modules (analog input, analog output, discrete I/O, etc.) Field Wiring Screw terminals (up to 14 AWG) Backplane Integral passive backplane with Fieldbus communication Power Supply 24 VDC field power (via external supply, distributed through carrier) LED Indicators Power present (optional, via FBM modules) Temperature Rating -20 °C to 70 °C operating Dimensions Standard vertical rack footprint Mounting Panel mount (bolt-on) Certifications CE, UL, CSA, Class I Div 2 (with appropriate FBM modules) Firmware / Software Versions & Upgrade Notes Here’s the straightforward part: the FBMSVH is a completely passive assembly. No processor. No memory. No firmware. No Firmware: The carrier is just a PCB with traces connecting the FBM modules to each other and to the field terminals. There’s nothing to upgrade. Hardware Revision: Look for Rev 3 or later on the label. Earlier revisions had a known issue with the terminal block torque specs—the screw terminals could loosen over time with thermal cycling. Rev 3 improved the terminal design. Configuration: All configuration happens in the Foxboro I/A Series software. You define which FBM is in which slot, assign channel numbers, and set parameters. The carrier itself is invisible to the software. Compatibility: Works with all FBM200 and FBM2000 series modules. Also compatible with the newer FBM300 series? No—300 series uses a different carrier (FBM303). Check before mixing.  Compatibility & Replacement Matrix Use this when building or expanding a Foxboro I/A Series I/O system. Original Model Replacement Model Compatibility Level Key Notes FBMSVH FBMSVH Drop-in Identical part. Direct replacement. FBMSVH FBMSH Needs Adaptation FBMSH is the horizontal mount version. Same electrical function, different physical orientation. May require cabinet rework. FBMSVH FBM207 Incompatible FBM207 is an individual I/O module, not a carrier. FBMSVH FBMSVH-10 Drop-in The -10 suffix indicates 10-slot (same as base model). Some vendors add it; it’s the same assembly. FBMSVH FBM303 Carrier Incompatible FBM300 series carriers use a different backplane pinout. FBM200 modules won’t work in them. IIMGC03 IIATB05 PLC IIMCP01 DCS IIMCL01 CPU IIAKB04 CPU IIATB04 PLC Email: [email protected] Phone: 86 15340683922 Sales:Wu Jiedong Our products are guaranteed for 1 year, with new and original production stopped and imported spare parts. All prices listed on the official website are subject to confirmation by contact: Wu Jiedong (manager). Our product: brand new original packaging Our warranty: All new or repaired parts have a 12 month warranty period beginning Our payment: 100% telegraphic transfer of inventory items before shipment, conditions can be proposed! If you have any downtime spare parts that you cannot find, please feel free to call or use email to contact me. If there are issues that the product cannot solve, please contact me. Product prices can be negotiated. Please do not consider contacting me!
