EPP302LCD Schneider Electric Pressure Sensor

PRESSURE-VEL DRY PANEL LCD 10I Product Specifications [Us] rated supply voltage 12…30 V DC 24 V AC Accuracy /- 1 % FS Application Air Velocity Monitoring Duct Pressure Monitoring Fan Monitoring Filter Monitoring VAV Control Brand Schneider Electric Burst Pressure 5 psid (34.5 kPa) By Schneider Yes Controlled Fluid Air Gas Depth 1.65 in (42 mm) Display Size 17 mm x 28 mm (0.7 ” x 1.1 “) Display Type LCD Electrical Connection – AWG 22 Final Result for Connectable Connectable ready Final Result for Flywheel performance tracking Connectable ready Fitting Size 6 mm (0.24″) Fitting Type Male Height 4.41 in (112 mm) Humidity Calibration Certificate None IP Degree of Protection IP65 Local Signalling Red/green/blue LED Location Plant Room Manufacturer Veris Industries Material ABS thermoplastic enclosure Brass Fitting Mounting Mode Panel Mounting Support Panel Net Weight 0.28 lb(US) (0.125 kg) Output Type Analog 0…10 V DC Analog 0…5 V DC Analog 3-wire 4…20 mA Pressure Measurement Drift Less than 0.5% Pressure Measurement Range 0…1″ W.C. (0…250 Pa) 0…10″ W.C. (0…2500 Pa) 0…2.5″ W.C. (0…500 Pa) 0…5″ W.C. (0…1000 Pa) Probe Diameter 0.28 in (7 mm) Probe Length 7.40 in (188 mm) Product Certifications CE Product Or Component Type Pressure transmitter sensor Sensor Model EPP302LCD Standards EN 61000-6-1 EN 61000-6-3 EN 61326-1 EN 61326-2-1 Temperature Ambient Operating Range -4…140 °F (-20…60 °C) Type Of Measurement Differential Pressure Width 3.46 in (88 mm) Wiring Technique 3-wire Documents Installation instructions   SpaceLogic Sensors, EP Series Installation Instructions Specification sheet   SpaceLogic Sensors, EP Series Specification Sheet
